Harness Layout - Main Harness (Cont'd) (R.H.D. Models)

EL-134component photoUnverified

R.H.D. MODELS. Main harness connector location chart, mirror of L.H.D. layout on EL-132. Connector positions are approximate due to dense overlapping bubbles; not every M-number in the sequence could be confidently located.

Continued from EL-133

Main Harness (Cont'd)

R.H.D. MODELS

Component LocationFig. fig1

Main harness layout (R.H.D.) showing routing through the cabin/dash and the location of the M-series connectors, the engine-compartment grommet (M86, M87) and body-ground points (M10, M54, M84, M85).

Main harness layout for R.H.D. models. Perspective view of the cabin/dash area showing main harness routing with numbered connector callouts in oval bubbles (M-series, M1 through M93 range). A grommet to the engine compartment is shown at lower centre. Four body-ground inset photos at right reference connectors M10, M84, M54 and M85; another lower-centre inset shows M85/M86/M87/M68.

MEL923B

1M-series connectors(Distributed across cabin/dash along main harness route)

2Engine compartment(Lower centre grommet: M86, M87)

3Body ground(Inset photos: M10, M84, M54, M85)
