Nissan Micra K11 silhouetteK11

OUTER COMPONENT PARTS — Rocker Cover (Cont'd)

EM-12prose procedure

A/T-only step 6 references A/T kickdown cable; M/T omits.

Continued from EM-11

Rocker Cover (Cont'd)

Rocker cover assembly (cont'd)

  1. 3
    Fit the cover. Tighten the bolts in the sequence shown to the correct torque.
    Rocker cover bolt-tightening sequence diagram with numbered bolt positions ①–⑩ around the cover perimeter. Instruction 'Tighten in numerical order.'.
    NEM050
  2. 4
    Recheck bolts.
  3. 5
    Check a third time.
  4. 6
    Reconnect the hoses and A/T cable (if fitted).
  5. 7
    Refit spark plug leads.
