ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION - EURO-OBD Diagnostic Trouble Code (DTC) (Cont'd)

AT-7021prose procedure
Continued from AT-7020

EURO-OBD Diagnostic Trouble Code (DTC) (Cont'd)

The following emission-related diagnostic information is cleared from the ECM memory when erasing DTC related to EURO-OBD. For details, refer to EC section ("Emission-related Diagnostic Information", "ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION").
Diagnostic trouble codes (DTC)
1st trip diagnostic trouble codes (1st trip DTC)
Freeze frame data
1st trip freeze frame data
System readiness test (SRT) codes
Test values
Distance traveled while MI is activated
Others

HOW TO ERASE DTC (WITH CONSULT-II)

How to Erase DTC (with CONSULT-II)

  1. 1
    If the ignition switch stays "ON" after repair work, be sure to turn ignition switch "OFF" once. Wait at least 5 seconds and then turn it "ON" (engine stopped) again.
    Six-panel CONSULT-II screen-flow showing the DTC erase sequence. Top row left→right: DIAGNOSIS SYSTEM SELECTION (CVT / ENGINE) → DIAGNOSIS MODE SELECTION (WORK SUPPORT, SELF DIAGNOSIS, DATA MONITOR, TCM PART NUMBER) → SELF DIAGNOSIS DATA (DTC RESULTS, PNP SW/CIRC). Bottom row right→left: SELF DIAG RESULTS (DTC RESULTS / TIME: PNP SW/CIRC [P0705], 0) → DIAGNOSIS MODE SELECTION (WORK SUPPORT, SELF DIAGNOSIS, DATA MONITOR, ACTIVE TEST, FUNCTION TEST, DTC WORK SUPPORT) → DIAGNOSIS SYSTEM SELECTION (CVT / ENGINE).
    SAT681J
  2. 2
    Turn CONSULT-II "ON" and touch "CVT".
  3. 3
    Touch "SELF-DIAG RESULTS".
  4. 4
    Touch "ERASE". (The DTC in the TCM will be erased.) Then touch "BACK" twice.
  5. 5
    Touch "ENGINE".
  6. 6
    Touch "SELF-DIAG RESULTS".
  7. 7
    Touch "ERASE". (The DTC in the ECM will be erased.)
