SUNROOF — Removal Procedures (Sunroof lid / Shade / Sunroof assembly / Link & wire)

BF-43prose procedure

Sunroof teardown is sequential — lid first, then shade, then sunroof assembly (after headlining), then link & wire assembly. Always work with a helper (heavy + risk of dropping glass). Mark all alignment points before removing anything.

Continued from BF-42

NOTE

After any adjustment, check sunroof operation and lid alignment. Handle finisher plate and glass lid with care so not to damage it. It is desirable for easy installation to mark each point before removal.

CAUTION

a. Always work with a helper. b. Remove sunroof frame from rear door opening.

REMOVAL — Sunroof lid assembly

Sunroof lid assembly — removal

1
Open sunroof shade.
2
Close sunroof lid.
3
Remove side trim clips.
4
Remove nuts securing sunroof lid assembly to link assembly.

REMOVAL — Shade assembly

Shade assembly — removal

5
After removing sunroof lid assembly, remove screws securing rear drains to roof.
6
Remove rear drain rail.
7
Remove shade assembly.
MBF954A1

REMOVAL — Sunroof assembly

Sunroof assembly — removal

8
Remove headlining. For details, refer to 'ROOF TRIM' in 'Interior'.
9
Disconnect drain hoses.
10
Remove nuts and bolts securing sunroof rail to roof.
11
Remove sunroof assembly.

REMOVAL — Link & wire assembly

Link & wire assembly — removal

12
After removing shade assembly and sunroof assembly, remove screws securing holders to sunroof rail.
13
Remove wind deflector.
14
Remove screws securing guide stoppers to sunroof rail.
