INTERIOR AND EXTERIOR — Exterior (Cont'd) — Sunroof / Door Weatherstrip / Door Waist Molding / Rear Door Parting Seal

Callout (6) Clip B is unusual — the rubber must be trimmed to leave 1-3 mm of cut-off portion past the clip; otherwise the weatherstrip will not seat properly. Door waist molding piece count is the only 3-door vs 5-door difference for callout (7).
